Accel

SUPER COIL, COIL-ON-PLUG, LATE MODEL FORD

SUPER COIL, COIL-ON-PLUG, LATE MODEL FORD

These coils feature advanced bobbin technology, highly specialized silicone magnetic steel cores, optimized winding, resistance, and turns ratios to deliver 10-15% more energy than the OEM coils. Specialized high temperature epoxy resists shock and vibration, while increasing thermal conductivity. These are direct replacements for OEM coils. Bodies and/or secondary towers molded in ACCEL yellow.

Applications:
1998-2008 Ford 4.6L/5.4L/6.8L
modular 2 valve direct fire engines . . . . . . . . . . . . . . . 140032
8-Pack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 140032-8
2004-2008.5 Ford 4.6L/5.4L
modular 3 valve direct fire engines . . . . . . . . . . . . . . . 140033
8-Pack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 140033-8
1997-2008 Ford 4.6L/5.4L
modular 4 valve direct fire engines . . . . . . . . . . . . . . . 140034 8-Pack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 140034-8

SUPER COIL, HEI IN-CAP GM

ACCEL, HEI In-Cap Super Coils are engineered for higher energy output resulting in quicker starting, improved idle quality, crisper throttle response and more high RPM power. Compatible with both original HEI ignition systems and later model computer controlled HEI systems. No need to remove or re-time distributor. Special high temperature epoxy resists shock and vibration, while increasing thermal conductivity. Finned injection molded coil cover with integral wire hold down ring, provides efficient cooling ensuring long life and great looks. Complete with simplified ground strap, mounting screws, silicone coil gasket and carbon contact brush / spring.

P/N 140003 has red and yellow primary wire. Typical HEI applications include Chevrolet 90 degree V6 & most V8, Cadillac V8.
P/N 140005 has red and white primary wire. Typical HEI applications include Buick V6 and V8, Oldsmobile V8, Pontiac V8, 1981-91 Corvette.

Specifications:
Primary Resistance . . . . . . . . . . . . . . . . . .0.5 Ohms
Secondary Resistance . . . . . . . . . . . . . .8.6 k Ohms
Turns Ratio . . . . . . . . . . . . . . . . . . . . . . . . . . . .80: 1
Maximum Voltage . . . . . . . . . . . . . . . . .45,000 volts
Peak Increase in Energy vs. OE . . . . . . . . . . . . .14%
Peak Increase in Voltage vs. OE . . . . . . . . . . . . .18%

SUPER COIL, DODGE "MAGNUM" TRUCK / JEEP 1990-97

Engineered with optimized low resistance, high turns ratio windings around an M36 high silicone magnetic steel C-core for higher energy and voltage outputs. Results in quicker starts, improved idle quality, crisper throttle response and more high RPM power. Compatible with late model Dodge/Jeep J-TEC computer controlled ignition system and MOPAR Performance ignition computers. Direct bolt-in, plug-in replacement. Can also work with an ACCEL, Mallory, Crane, Holley or MSD capacitive discharge ignition systems. Special high temperature epoxy resists shock and vibration, while increasing thermal conductivity. Brass coil wire contact increases energy transfer efficiency and resists corrosion better than aluminum. High dielectric strength "ACCEL Yellow" over molded housing.

P/N 140021 Dodge "Magnum" Truck / Jeep 1990-97

Specifications:
Primary Resistance . . . . . . . . . . . . . . . . . .1.0 Ohms
Secondary Resistance . . . . . . . . . . . . .12.7 k Ohms
Turns Ratio . . . . . . . . . . . . . . . . . . . . . . . . . . . .76 : 1
Maximum Voltage . . . . . . . . . . . . . . . . .42,000 volts
Peak Increase in Energy vs. OE . . . . . . . . . . . . .34%
Peak Increase in Current vs. OE . . . . . . . . . . . . .17%
Peak Increase in Arc Duration vs. OE . . . . . . . . .23%
Peak Increase in Dwell vs. OE . . . . . . . . . . . . . .36%

SUPER COIL, GM HEI REMOTE MOUNT 1996-2007

Engineered with optimized low resistance, high turns ratio windings around an M36 high silicone magnetic steel E-core for higher energy and voltage outputs. Results in quicker starts, improved idle quality, crisper throttle response and more high RPM power. Compatible with late model GM computer controlled remote mount HEI systems. Direct bolt-in, plug-in replacement. Can also work with an ACCEL, Mallory, Crane, Holley or MSD capacitive discharge ignition system. Special high temperature epoxy resists shock and vibration, while increasing thermal conductivity. Brass coil wire contact increases energy transfer and resists corrosion better than aluminum. Complete with new mounting hardware. High dielectric strength "ACCEL Yellow" over molded housing.

P/N 140024 GM HEI Remote Mount 1996-2007

Specifications:
Primary Resistance . . . . . . . . . . . . . . . . . .0.2 Ohms
Secondary Resistance . . . . . . . . . . . . . .6.7 k Ohms
Turns Ratio . . . . . . . . . . . . . . . . . . . . . . . . . . . .92 : 1
Maximum Voltage . . . . . . . . . . . . . . . . .48,000 volts
Peak Increase in Energy vs. OE . . . . . . . . . . . . .11%
Peak Increase in Voltage vs. OE . . . . . . . . . . . . . .7%

Back to top

IGNITION COILS, SUPER COILS; RACE - UNIVERSAL

Super Stock POINTS COILS, UNIVERSAL

Excellent high performance replacement for import and domestic vehicles with a canister type oil filled can coil. Re-engineered windings for even higher energy output resulting in quicker starting, improved throttle response and more high RPM power. Designed to work with both points style and breakerless electronic ignition systems. Special crimped and soldered internal connections ensure positive contacts. Heavy duty black Alkyd tower provides "flashover" protection to primary terminals. Available in "ACCEL Yellow" or Chrome Plated can. Effective to 6,500 RPM.

Specifications:
Primary Resistance . . . . . . . . . . . . . . . 1.4 Ohms
Secondary Resistance . . . . . . . . . . . . . . 9.2 k Ohms
Turns Ratio . . . . . . . . . . . . . . . . . . . 94 : 1
Maximum Voltage . . . . . . . . . . . . . . . . 42,000 volts

SUPER COIL, UNIVERSAL

Engineered for faster rise time, longer spark duration and increased performance. Unique design with premium grade wire, special low resistance, high turns ratio windings. Produces higher spark energy with breakerless electronic ignition systems. For points applications the supplied 0.85 Ohms ballast resistor must be used in conjunction with the vehicle's original ballast resistor, if so equipped. Oversized molded case with integral cooling fins and high capacity oil filled construction provide high thermal conductivity ensuring cool operation and long life. Extra tall tan Alkyd tower and integral voltage dam eliminate "flashover" to primary terminals. Comes complete with mounting hardware and 0.85 Ohms ballast resistor. Effective to 6,500 RPM.

Specifications:
Primary Resistance . . . . . . . . . . . . . .0.7 Ohms
Secondary Resistance . . . . . . . . .11.8 k Ohms
Turns Ratio . . . . . . . . . . . . . . . . . . . . . . . .70 : 1
Maximum Voltage . . . . . . . . . . . . .45,000 volts

Super Stock BREAKERLESS ELECTRONIC, UNIVERSAL

Excellent high performance replacement for import and domestic vehicles with a canister type oil filled can coil. Re-engineered windings for even higher energy output resulting in quicker starting, improved throttle response and more high RPM power. Designed to work with both points style and breakerless electronic ignition systems. Special crimped and soldered internal connections ensure positive contacts. Heavy duty black Alkyd tower provides "flashover" protection to primary terminals. Available in "ACCEL Yellow" or Chrome Plated can. Effective to 6,500 RPM.

Specifications:
Primary Resistance . . . . . . . . . . . . . .1.4 Ohms
Secondary Resistance . . . . . . . . . .9.2 k Ohms
Turns Ratio . . . . . . . . . . . . . . . . . . . . . . . .94 : 1
Maximum Voltage . . . . . . . . . . . . .42,000 volts

SUPER COIL, HEAVY DUTY "CD ONLY" E-CORE, RACING

Professional continuous use racing coil specifically designed to work with CD ignition systems only. High energy, heavy gauge windings designed for optimum performance with an ACCEL, Mallory, Crane, Holley or MSD capacitive discharge ignition system. E-core design minimizes inductance losses and maximizes energy output. Special high temperature epoxy resists shock and vibration and provides excellent thermal conductivity. The extruded aluminum heat sink provides maximum cooling to ensure long life. SAE male tower offers greater coil wire retention and protection from arcing. Complete with insulated primary wire connector, universal ACCEL 8.8mm 300+ Race Wire coil lead and mounting hardware kit. Effective to over 10,000 RPM.

Specifications: - Tested with ACCEL 500+ Ignition
Primary Resistance . . . . . . . . . . . . . . . . . .0.2 Ohms
Secondary Resistance . . . . . . . . . . . . . .3.6 k Ohms
Turns Ratio . . . . . . . . . . . . . . . . . . . . . . . . . . . .95 : 1
Maximum Voltage . . . . . . . . . . . . . . . . .48,000 volts
Peak Current . . . . . . . . . . . . . . . . . . . . . . . . .300 mA
Spark Duration . . . . . . . . . . . . . . . . . . . . . . . .360 µS

Back to top

DISTRIBUTORS

PERFORMANCE REPLACEMENT™ DISTRIBUTORS

Whether you are thinking about replacement parts or upgrade components for your vehicle, Performance Replacement Distributors are your best choice. Crafted from all-new components, they feature:

  • High-performance electronics suite
  • Encasements are either cast new or converted from Billet stock
  • Coreless ground steel shaft with oil-lite bushing lower
  • High-limit dielectric strength cap and a balanced rotor for worry-free performance
  • Male-polarized tower distributor cap with brass cap and rotor contacts (Ford- and AMC-specific models feature screw-mounted wire retainer for secure retention)
  • Sturdy iron or steel distributor gear
  • Direct plug-in replacement with factory-style connectors offer the convenience of "plug-and-play" installation

PERFORMANCE REPLACEMENT™ DISTRIBUTOR FOR THE GM OPTI-SPARK II

Whether you are thinking about replacement parts or upgrade components for your vehicle, Performance Replacement Distributors are your best choice. Crafted from all-new components, they feature:

Perfect replacement for OE Unit Featuring:

  • Polished aluminum housing with heavy duty Oil lite bushings
  • High dielectric strength glass reinforced cap
  • Epoxy over mold and brass contacts with balanced rotor, cross flow vent design
  • Pin drive shaft seals and installation hardware

STREET BILLET PERFORMANCE ELECTRONIC BREAKERLESS DISTRIBUTORS

  • Ready to run, self-contained electronic breakerless design
  • 12-volt breakerless 6.5 Amp dwell control module
  • CNC-machined billet 6061-T6 aircraft grade aluminum housing
  • Centerless ground steel shaft with upper and lower Oil Lite bushings
  • Easy access top mount fully adjustable and lockable mechanical advance with nylon pads to ensure long term smooth operation
  • Adjustable vacuum advance, with lockout insert for mechanical advance only operation
  • Male HEI tower distributor cap with wire retainer injection molded in GE Valox glass reinforced material for both high strength & high dielectric properties. Brass inserts for excellent long term high conductivity
  • Convertable to traditional style female points tower by using ACCEL p/n 8120 cap & rotor kit
  • Easy 3-wire hookup with isolated ground circuit and weather tight connector
  • Steel alloy drive gear, compatible with either flat tappet or hydraulic roller camshafts
  • Race-proven high output magnetic pick assembly
  • Recommended electronic breakerless coils with 0.7 Ohms or less of primary resistance; ACCEL p/n's; 8145, 8145C, 8140HV, 140001 or 140008
  • Compatible with CD ignition systems

STREET BILLET application coverage
52100 . . . . . . . .All Std. Deck Height Chevrolet V8 engines (except 348 & 409)
52301 . . . . . . . .1965-1993 Chrysler/Dodge/Plymouth 273, 318 (1967 - later) 340 & 360 "LA" engines (except Dodge "Magnum" 5.2L/5.9L engines)
52103 . . . . . . . .1964-90 Oldsmobile 260, 307, 330, 350, 400, 403, 425 & 455 engines
52201 . . . . . . . .1962-80 Ford 221, 255, 260, 289, 302 & 302 Boss engines
52202 . . . . . . . .1968-95 Ford 351C, 351 Boss, 351M, 400, 429 & 460 engines

BILLETECH™ DISTRIBUTORS

BilleTech™late model replacement distributors are the perfect replacement for the factory distributor in your late model car or truck. All BilleTech™ distributors feature:

  • 6061 T6 Billet aluminum housing
  • Centerless ground steel shaft
  • 10,000 RPM bearing upper with oil lite bushing lower
  • Performance electronic pick up and module (where noted)
  • High dielectric strength cap, balanced rotor for trouble free performance
  • Brass cap contacts
  • Iron or Steel distributor gear compatible with flat tappet cams and OEM hydraulic roller camshafts
  • May be used with an ACCEL, Mallory, Crane, Holley or MSD capacitive discharge ignition system

Featured Vortec Distributors:
Distributor for Chevy 97-07 4.3L Vortec V6 ................................60115
Distributor for Chevy 96-03 5.0/5.7/7.4L, 96-02 7.4L Vortec V8........................60116

Distributor Cap & Rotor Kit - HEI Style

The ACCEL 8132 distributor cap and rotor kit fits HEI style distributors. ACCEL cap and rotor kits offer superior protection from "arc-thru" and crossfire. Features:

  • 60k V-rated alkyd compound
  • Stress-relieved at molding to ensure stability
  • Brass inserts and steel rotor springs provide for high spark energy flow

Distributor Cap - Chevy / GMC Vortec - V6 & V8 - Socket Style - Crab - Black

ACCEL Heavy-Duty Caps offer superior protection from arc-thru and crossfire. ACCEL distributor caps are black, socket style heavy duty caps. Features:

  • Hi-performance 60,000 volt alkyd compound.
  • Stress-relieved at molding to ensure stability.
  • Brass inserts provide for high spark energy flow
  • Heavy duty for maximum energy transfer

Distributor cap for Vortec V8........ 120141
Distributor cap for Vortec V6........ 120142

HEI Corrected Cap - Distributor Cap for GM HEI

ACCEL 8141R corrected distributor cap for GM HEI prevents arcing from crossover and keeps your engine compartment neat. ACCEL Heavy-Duty Caps offer superior protection from arc-thru and crossfire. Features:

  • Hi-performance 60,000 volt alkyd compound.
  • Stress-relieved at molding to ensure stability.

Back to top

SPARK PLUG WIRES

ACCEL CUSTOM FIT CERAMIC WIRE KITS

ACCEL now offers the cure for burnt spark plug boots with Extreme 9000 Ceramic wire kits. The 8mm Ferro - Spiral core wire now has ceramic boots on the spark plug end of the wires. The ceramic boots will withstand up to 2,000 degrees Fahrenheit. If you are running headers with close tolerances, have an engine bay with little room, or an RV with boots that melt because of heat, these wire kits are the solution! The Extreme 9000 Ceramic wire sets have ultra high temperature double silicone construction wire rated at 600 degrees Fahrenheit peak. The wire uses a 500 Ohms/ft Ferro-Spiral™ core developed for performance use. It provides excellent energy delivery to the spark plugs, while providing the highest level of RFI/EMI suppression. The Extreme 9000 Ceramic wires also feature stainless steel spark plug terminals for maximum spark energy to the plugs.

9000 SERIES

  • 8mm, double silicone wire 600° F-rated
  • Ceramic boots rated at 2000° F
  • 500 Ohms/ft Ferro-Spiral™ core developed for performance use
  • Provides the highest level of RFI/EMI suppression
  • Stainless steel plug terminals for high electrical conductivity and corrosion resistance
  • Available in Custom-fit and Universal

Extreme 9000 Universal Ceramic Wire Kits :
180 degree Straight boots w/ terminals for male and female tower caps . . . . . . . . . . . . . . . . . . . .9000C
90 degree 5/8" Hex plug boots w/ terminals for male and female tower caps . . . . . . . . . . . . . . . .9001C
115 degree Ford style boots w/ terminals for male and female tower caps . . . . . . . . . . . . . . . . . .9002C

SUPER STOCK SPIRAL SPARK PLUG WIRE SETS

The traditional combination of yellow wire and red spark plug boots has been added to the existing SuperStock Spiral product line, which features color matched wire and spark plug boots in blue, black and red. With only 500 Ohms/foot of resistance, more ignition energy can reach the spark plug, producing a hotter, longer-lasting spark flame kernel. The result is higher performance through improved efficiency, quicker throttle response and reduced emissions. This 8mm wire's double silicone construction is rated to 550° F. The high gross wire jacket resists moisture, chemicals and heat extremes for longer life and great looks. The fiberglass braid adds greater pull strength and terminal retention, while the stainless steel spark plug terminals provide excellent long life, electrical conductivity and corrosion resistance. Both universal and custom fit applications are available for early and late model cars and trucks.

5000 SERIES

  • 7mm & 8mm, 550° F-rated
  • Street-driven applications
  • 8mm red, blue, black or yellow high temperature silicone jacket resists moisture, chemicals and severe temperatures
  • High-strength fiberglass braid for added "pull strength" silicone insulation eliminates arcing
  • Stainless steel plug terminals for high electrical conductivity and corrosion resistance
  • Pre and post HEI applications
  • Custom-fit and universal

SUPER STOCK SPIRAL SPARK PLUG WIRE SETS

Our SuperStock Wire is designed to upgrade an OE ignition system for high spark delivery levels for street-driven applications. The 450° F-rated silicone jacket is extruded over a tightly woven, rugged fiberglass braid which is applied over a high dielectric strength EPDM (Ethylene Propylene Diene Monomer) inner insulation for ignition wire performance that exceeds SAE specifications.

4000 SERIES

  • 8mm yellow, red, black & blue silicone jacket
  • Street-driven applications
  • Fiberglass braid EPDM insulation
  • Orange and color matched blue, red & black silicone spark plug boots
  • Pre and post HEI vehicles
  • Custom Fit, Universal & Import

3000 SERIES

  • 7mm yellow, blue silicone jacket
  • Street-driven applications
  • Graphite RFI Suppression or Copper Core
  • Orange and color matched blue silicone spark plug boots
  • Pre HEI vehicles
  • Universal Fit

300+ FERRO SPIRAL SPARK PLUG WIRE SETS

The traditional combination of yellow wire and red spark plug boots has been added to the existing SuperStock Spiral product line, which features color matched wire and spark plug boots in blue, black and red. With only 500 Ohms/foot of resistance, more ignition energy can reach the spark plug, producing a hotter, longer-lasting spark flame kernel. The result is higher performance through improved efficiency, quicker throttle response and reduced emissions. This 8mm wire's double silicone construction is rated to 550° F. The high gross wire jacket resists moisture, chemicals and heat extremes for longer life and great looks. The fiberglass braid adds greater pull strength and terminal retention, while the stainless steel spark plug terminals provide excellent long life, electrical conductivity and corrosion resistance. Both universal and custom fit applications are available for early and late model cars and trucks.

300+ RACE; UNIVERSAL FIT SPARK PLUG WIRE SET & CUSTOM FIT SPARK PLUG WIRE SET

These ACCEL 300+ wire sets are designed for race engines and their builders. ACCEL 300+ race wire Universal Spark Plug Wire Sets & Custom Spark Plug Wire Sets have a spiral core and black silicone jacket.

  • 8.8mm oversize silicone jacket
  • 150 ohms per foot
  • Wire is rated for 600 degrees F and 60kV.
  • Resists heat, chemicals and moisture.
  • High density insulation eliminates arcing.

Back to top

TUNE UP KITS

Truck Super Tune Up Kits

Everything you need to Super Tune your pickup truck, van or SUV! Applications covering most Chevrolet, Dodge, Ford, GMC, Cadillac and Jeep late model 6 & 8 cylinder applications.

  • 8mm Custom fit Extreme 9000 wire set with Heat reflective Coat spark plug boots rated to 1200°F.
  • Double silicone wire with low resistance Ferro-Spiral™ core.
  • (Some in-line 6 cylinder application use 5000 Series wire set where extreme heat is not a problem.)

We use the finest distributor cap and rotors available, precision molded in impact resistant high dielectric strength compounds. Most applications have tan caps with brass or copper inserts and stainless steel contact springs. Renowned, race-proven copper core spark plugs maximize burn efficiency for improved performance and reduced emissions and are included FREE with every kit! Kits designated with the HP suffix come with ACCEL Shorty Header Spark Plugs for added plug clearance on vehicles equipped with headers. Not all kits are available with header plugs.

FUEL INJECTORS

DIGITAL FUEL INJECTION PRODUCTS AND ACCESSORIES

Why Fuel Injection Over A Carburetor?

  • Easy Starting in all weather conditions
  • Better Idle Control with all engine combos
  • Improved Acceleration / Throttle Response
  • Improved Fuel Economy by 30% +
  • Reduced Emissions (GO GREEN)
  • Increased Horsepower and Torque
  • Better control over any power adder especially Nitrous
  • The end of blowing your carburetor through the hood while using Nitrous Oxide
  • No need to carry spare spark plugs
  • The end of re-jetting the carburetor
  • No need to buy a different carburetor because you changed the cam or heads
  • AC Clutch Control, Cooling FAN Control, Knock Control

Why ACCEL DFI?

  • The DFI EFI System offers the best overall Performance and Drivability over any carburetor and other EFI systems
  • The only true aftermarket V.E. Based System
  • Individual Cylinder Fuel control!!!
  • Only system in its class with built in BAROMETRIC Sensor. (Great while driving though mountains)
  • OEM style diagnostics with CHECK ENGINE LIGHT
  • Limp Home Mode technology (Never leave your car on the side of the road if a sensor fails)
  • We cover more applications
  • We Engineer & Build Precision Components to fit each application
  • We have the only Complete Plug & Play Systems
  • The only true EFI supported system through our EMIC Dealer Network (117 EMIC Locations Nationwide and growing)
  • Our Pricing is very competitive
  • Our commitment to our customers is unwavering

New Media

Uploaded videos

Learn more about Mallory FireStorm and its features and benefits as well as available products.

Featured Accel Parts
